Packaging and Converting
| Diecutters, Digital Printing | |
| Reference: | 5743 |
| Year: | 2020 |
| Price: |
Price request
|
| Description | |
| Size: 76x106 cm, Flatbed Laser digital cutting and creasing machine with max speed of 5000 S/H, for corrugated board flutes F, E, up to 2mm | |
| Diecutters | |
| Reference: | 5793 |
| Year: | 2001 |
| Price: |
Price request
|
| Description | |
| Size 74 x 104 cm, Stripping and blanking unit, 1st owner since new | |
| Packaging machines | |
| Reference: | 4976 |
| Year: | 2018 |
| Price: |
Price request
|
| Description | |
| Automatic blanking machine, for blanking two different forms or nested forms. max press 7Mpa, speed 500-800 cycles/h, max blanking size 520x380mm, min. blanking size 30x30mm, max blanking hight 600-95 mm, PLC contolled, Touch screen, max paper size 1080x780 mm, min. paper size 540x410 mm, machine outlines 4310x1750x1950 mm, power supply 380V 50Hz 6,7 Kw | |
| Packaging machines | |
| Reference: | 4975 |
| Year: | 2018 |
| Price: |
Price request
|
| Description | |
| Automatic blanking machine, for blanking two different forms or nested forms. max press 7Mpa, speed 500-800 cycles/h, max blanking size 520x380mm, min. blanking size 30x30mm, max blanking hight 600-95 mm, PLC contolled, Touch screen, max paper size 1080x780 mm, min. paper size 540x410 mm, machine outlines 4310x1750x1950 mm, power supply 380V 50Hz 6,7 Kw | |
| Folder gluers | |
| Reference: | 5765 |
| Year: | 2017 |
| Price: |
Price request
|
| Description | |
| Automatic Carton Folder Gluer, Max open blank width : 1100 mm, Min open blank width : 126 mm, Max feed up length : 800 mm, Min feed up length : 60 mm Stock : Cartonboard up to 800 gsm, Corrugated up to E flute.Max belt speed i: 425 m/min Complete with : Bottom belt feeder, Back lifters with vibration for smooth and consistent feeding, Pre-breaking system, Small box attachment - allowing min 76mm open blank width, Crash-lock module, Bottom left hand side glue pot, Three belt carrier folding section, Heavy duty Double Trombone delivery, Compression belt section, HHS C-1100 8 B cold glue system, 4 x HHS glue guns, Remote control, Manuals and electrical diagrams. | |
| Diecutters | |
| Reference: | 5777 |
| Year: | 1984 |
| Price: |
Price request
|
| Description | |
| Size 72 x 102 cm, 7500 s/h, Swiss made machine, New clutch | |
| Diecutters | |
| Reference: | 5792 |
| Year: | 1987 |
| Price: |
Price request
|
| Description | |
| Size 72 x 102 cm, 1st owner since new | |
| Folder gluer Jagenberg | |
| Reference: | 5649 |
| Year: | 1999 |
| Price: |
Price request
|
| Description | |
| Jagenberg packing device for folder gluers | |
| Packaging machines | |
| Reference: | 5795 |
| Year: | 1988 |
| Price: |
Price request
|
| Description | |
| Gietz FSA 720 Foil / stamping embossing press. size 720x520 mm, minimum sheet size 297x210, Double sheet detection, pressior 120 t, max speed 5000 sheets/h, pile hight 950 mm with max 700kg, pile height on delivery 700mm, dementions of the machine 380x280x195 cm. | |
| Laminating Machines | |
| Reference: | 5727 |
| Year: | 2003 |
| Price: |
Price request
|
| Description | |
| Max sheet 1400 x 1600 mm, Top sheet: 130 - 450 gm/m2 ; Bottom sheet: from 250 gm/m2, Thickness: 0,6 - 10 mm. Feeder height: Bottom: 1600 mm, Top: 800 mm, Registration accuracy:* ± 0,5 mm Operating speed:* Up to 3000 sheets/hour | |
| Folder gluer Jagenberg | |
| Reference: | 5650 |
| Year: | 1993 |
| Price: |
Price request
|
| Description | |
| Feeder for folder gluer | |
| Laminating Machines | |
| Reference: | 5574 |
| Year: | 2008 |
| Price: |
Price request
|
| Description | |
| Size 52 x 74 cm, Automatic feeding, Adjustable side bracket, Temperature control by sensor, Pneumatic pressure roller. | |
| Diecutters | |
| Reference: | 5289 |
| Year: | 1997 |
| Price: |
Price request
|
| Description | |
| For Sale at Prestotype, the Purlux PYQ1040C Creasing & Cutting machine for the Graphical art Industry. <br />This Shanghai produced graphic machine is from 1997. The handed Platen cuts up to size 74 x 104. <br /><br />Please contact <a href="mailto:sales@prestotype.com">sales@prestotype.com</a> for more information, price, photos or video of the Purlux PYQ1040C die cutter. Refer to reference number <span>5289 or machine 704. </span> | |
| Seal Machines | |
| Reference: | 5685 |
| Year: | 2002 |
| Price: |
Price request
|
| Description | |
| Max. pallet height 2400 mm; film width 400 to 600 mm; Max. roll Ø 300 mm; Max. pallet size 1200x1000 mm; v.v. digital control | |
| Reference: | 5554 |
| Year: | 2001 |
| Price: |
Price request
|
| Description | |
| Automatic seal machine | |
| Seal Machines | |
| Reference: | 5407 |
| Year: | 1999 |
| Price: |
Price request
|
| Description | |
| Semi automatic seal machine. | |
| Diecutters | |
| Reference: | 5717 |
| Year: | 2014 |
| Description | |
| Formaat 56 x 76 cm, Snelheid ca. 8000 per uur Prijs inclusief Transport, installatie en training € 195.000 | |
